Intel? 單口千兆服務器網卡PRO/1000 PF

Intel? 單口千兆服務器網卡PRO/1000 PF

The Intel? 單口千兆服務器網卡PRO/1000 PF family provides the dedicated I/O bandwidth of PCI Express* (PCIe), without bus sharing, for Gigabit Ethernet connectivity in Category-5 networks. The Intel? 單口千兆服務器網卡PRO/1000 PF are designed to provide high performing Gigabit Ethernet connectivity and feature 10/100/1000 Mbps self-configuration for compatibility with mixed-speed network devices.
High-performance, self-configuring 10/100/1000 Mbps connection for PCIe slots
Multi-Gigabit scalability and increased uptime through advanced server features
Optional low-profile bracket included for high-density, rack-mounted servers
See Intel’s latest generation Gigabit Ethernet Server Adapters >

Features and specifications

Intel? 單口千兆服務器網卡PRO/1000?
Intel? 單口千兆服務器網卡PRO/1000 PF Product code EXPI9400PT EXPI9400PTBLK EXPI9400PF EXPI9400PFBLK EXPI9402PF EXPI9402PFBLK
Ethernet controller Intel? 82572 Intel? 82572 Intel? 82571
Connector and cable RJ-45 Copper Fiber optic Fiber optic
Cable type Category-5 up to 100 m MMF 62.5/50 μm up to 275 m MMF 62.5/50 μm up to 275 m
Slot type, maximum bus speed, and slot width PCI Express* 2.0 2.5 GT/s Lane x 1 Lane PCI Express* 2.0 2.5 GT/s Lane x 4 Lane PCI Express* 2.0 2.5 GT/s Lane x 4 Lane
Ports Single port Single port Dual port
Supported slot heights Low profile and full height Low profile and full height Low profile and full height
Intelligent offloads Yes Yes Yes
Intel? Virtualization Technology for Connectivity N/A N/A N/A
Storage over Ethernet iSCSI, NFS iSCSI, NFS iSCSI, NFS
Ethernet power management NA NA NA
Product support page Intel? PRO/1000 PT Server Adapter Intel? PRO/1000 PF Server Adapter Intel? 單口千兆服務器網卡PRO/1000 PF Dual Port Server Adapter
